BLE 7.5inch Double Sides Table-top Sign E-ink Meeting Room Signage Eink Name Plates
- Model
- E-ink Meeting Room Signage SETPB0750R_D
Item specifics
- Display Size
- 7.5inch
- Dimension
- 176.2mm(V) ×137.5mm(H)×80mm(D)
- ESL Operating Frequency
- 2.4G BLE
- Display Color
- Black, White and Red
- Display Resolution
- 640(H)×384(V)
- Key Word
- digital table-top signage or name plates
- Battery Life
- Not less than 5 years, Replaceable
- Battery
- CR2450*6
Review
Description
7.5inch Double Sides Table-top Sign E-ink Meeting Room Signage Eink Name Plates
Features
- Low power consumption, 5-year lifetime for battery
- 2.4G carrier wave, encryption commnication
- E-Paper displays,640x3840pixels full graphic, double sides
- Wireless device Android Phone/pad
|
Product Model
|
SETPB0750R_D
|
Size (mm)
|
176.2*137.15*80
|
|
Display Technique
|
The e-ink screen displays on both sides
|
Display Area (mm)
|
163.2(H) * 97.92(V)
|
|
Resolution (Pixel)
|
800*480
|
Appearance Color
|
Silvery
|
|
Display Color
|
Black / White / Red
|
Visual Angle
|
180°
|
Working Temperature | 0~40℃ | Working Voltage | 3.0V (Minimum: 2.2V) |
Duration of Flight | 3-5 years (Updated twice a day) | Use Frequency Range | 2.400~2.480Ghz (Bluetooth 5.0) |
Support Content Format | Text / Picture / QR code / Bar code | Product Weight | 250g |
Template Design | Yes | Soft and Hardware Encryption | Yes |
E-ink Meeting Room Signage Name Plates—System Architecture
7.5inch Double Sides Eink Name Plate Download
E-ink Meeting Room Signage Customer Case
